Jun 26, 2019 KROHNE IFC 010 Converter Short EN User Manual. Page 10 3 Start-up 3. Your manual failed to upload Page 8 Connection of shields to the IFC 1 DS Signal cable 2 Shield terminal for shielded signal cable 3 Field power cable 4 Shield terminal for shielded field power cable 5 Housing wall, signal converter 6 Cable entries 2 Electrical connection of outputs 2. Krohne IFC 010 F Manuals Manuals and User Guides for KROHNE IFC 010 F. We have 1 KROHNE IFC 010 F manual available for free PDF download: Installation And. Krohne IFC 010 F Manuals Manuals and User Guides for KROHNE IFC 010 F. We have 1 KROHNE IFC 010 F manual available for free PDF download: Installation And Operating Intructions. Krohne IFC 010 F Installation And Operating Intructions (67 pages) Signal converters intructions for. Read online or download PDF. Page 44 / 67. KROHNE IFC 010 Converter EN User Manual. KROHNE Equipment. 8.4) or contact Krohne Service. Krohne Ifc 080 Manual Installation and operating intructions IFC 010 K IFC 010 F The primary head must be unit 8/4 IFC 080 and SC 80 AS Replacement of electronic unit by IFC 010 8/4 However, in the measuring mode, manual sequencing can be carried out. The IFC 100 signal converter is designed to. The modular KROHNE system with the IFC 090 signal converter The IFC 090 signal converteris compatible with all KROHNE primary heads: Type code K Integral systems: Primary head and signal converter form a single unit and are solidly connected. F Remote systems: Primary head and signal converter are remote units and electrically connected. Jun 26, 2019 KROHNE IFC 010 Converter Short EN User Manual. Page 10 3 Start-up 3. Your manual failed to upload Page 8 Connection of shields to the IFC 1 DS Signal cable 2 Shield terminal for shielded signal cable 3 Field power cable 4 Shield terminal for shielded field power cable 5 Housing wall, signal converter 6 Cable entries 2 Electrical connection of outputs 2.
Part 2
Signal converter IFC 010 D (D = display version) and
Signal converter IFC 010 B (B = basic version), without display
but with HHT or CONFIG operator program (see Sect. 6.1)
Group D
Display shows . . .
Cause
Remedial action
D 1
LINE INT.
Power failure.
Delete error message in
Note: no counting during
RESET/QUIT. menu. Reset
power failure.
totalizer(s) if need be.
D 2
CUR.OUTP. I
Current output overranged.
Krohne Ifc 010 D User Manual Online
Check instrument parameters
and correct if necessary.
Error message deleted
automatically after cause
has been eliminated.
D 3
PULS.OUTP. P
Pulse output overranged.
Check instrument parameters,
Note: totalizer deviation
correct if necessary, and reset
possible
totalizer(s). Error message
deleted automatically
after cause has been
eliminated.
D 4
ADC
Analog/digital converter
Error message deleted
overranged.
automatically after cause
has been eliminated.
D 5
FATAL. ERROR
Fatal Error,
Replace signal converter
all outputs set to “min.”
(see Sect. 8.4) or contact
values.
Krohne Service, having
first noted down hardware
information and error status,
see Fct. 2.02.
D 6
TOTALIZER
Counts lost
Delete error message in
(overflow, data error)
RESET/QUIT. menu.
D 7
„STARTUP“
Hardware fault,
Replace signal converter
cyclic flashing
Watchdog activated.
(see Sect. 8.4) or contact
Krohne Service.
D 8
BUSY
Displays for flow,
Change setting in
totalizers and errors disabled.
Fct. 1.04.
D 9
Unsteady display
– Process product
Increase time constant,
–
conductivity too low,
see Sect. 6.1, or contact
–
particles/air inclusions
Krohne Service.
–
too large or inhomogeneous
– Pulsating flow
– Time constant too low
D 10
No display
Power OFF.
Switch on power
Check power fuse(s)
Replace if defective
F1 (F1 and F2 with DC).
(see Sect. 8.2).
Group I
Fault / Symptom
Cause
Remedial action
I 1
Receiver instrument
Incorrect connection/polarity
Connect properly,
indicates “0”.
see Sect. 2.3.
Receiver instrument or current
Check output (see Sect. 7.2)
output defective.
with new milliammeter:
Test ok, check connection
cables and receiver instrument,
replace if necessary.
Test faulty, current output
defective. Replace signal
converter (see Sect. 8.4)
or contact Krohne Service
Current output disabled,
Activate under Fct. 1.05.
see Fct. 1.05
Short-circuit between current
Check connection and cables,
output and pulse output.
see Sect. 2.3. Voltage between
I+ and I
⊥
approx. 15 V.
Switch off device, eliminate
short-circuit, and switch
device on again.
I 2
Unsteady display
– Process product
Increase time constant,
–
conductivity too low,
see Sect. 6.1, or contact
–
particles/air inclusions
Krohne Service.
–
too large or inhomogeneous
– Pulsating flow
– Time constant too low
